Product
Automatic Vaccine Glass Vial Liquid Filling Capping Machine
Details:
1. This machine is suitable for liquid metering and packing. Such as penicillin, collagen, pesticide , injection, essence, hyaluronic acid etc.
2. PLC touch screen control, easy to operate and maintain.
3. High precision screw or peristaltic pump control, high filling accuracy.
Description
Application
- This machine is suitable for liquid/powder metering and packing. Such as penicillin powder, collagen powder, pesticide powder, injection, essence, hyaluronic acid etc.
- PLC touch screen control, easy to operate and maintain.
- High precision screw or peristaltic pump control, high filling accuracy.
- Production speed can be adjusted, automatic counting.
- Made of 304 and 316L stainless steel, which fully meets the requirements of the GMP.
- Widely used in food, pharmaceutical, daily chemical and scientific research fields.
Feature
- Automatic bottle sorting;
- Automatic liquid/powder filling;
- Automatic lid placing;
- Automatic capping;
- Automatic finished bottle discharge.
Technical Parameters
| Model | SHH-4A | SHH-8A |
| Capacity | 20-50/min | 50-100/min |
| Filing head number | 4 | 8 |
| Filling volume | 2-100ml | 2-100ml |
| Filling accuracy | ≤ ±1% | ≤ ±1% |
| Capping rate | ≥ 99% | ≥ 99% |
| Power | 2KW | 3KW |
| Voltage | 220/380V, 50/60Hz | 220/380V, 50/60Hz |
| Weight | 500kg | 700kg |
| Dimension(L*W*H) | 2000*850*1650mm | 2500*1000*1700mm |
