SHH-DPB80 Automatic Tablet Capsule Blister Packing Machine
Details:
- Best option for small batches, pharmaceutical R&D and pilot plants.
- It allows forming thermoplastic and cold forming materials (Alu-Alu).
- It stands out for its siple operation, high reliability and compact design.
- Its main structure is made of stainless steel.
- it can used for capsule, tablet, gel, candy, etc. blister packing
Description
Application
SHH-DPB80 is a flat-plate aluminum-plastic blister packaging machine which integrates many functions including PVC feeding, PVC heating, PVC forming, PTP feeding, sealing of PVC and PTP, batch number printing, indentation line making, etc. It is suitable for all kinds of capsules, tablets, sugar coated tablets, honey pills, injections, ampoules, etc. The products have the characteristics of long shelf life, good sealing performance, beautiful appearance, safety and hygiene, conforming to the GMP production standards.
Common packaging products:
tablets, pills, capsules, honey, electronic cigarettes, perfume, butter, tomato paste, soft capsule, candy, etc.
Feature
Remarks：
- Best option for small batches, pharmaceutical R&D and pilot plants.
- It allows forming thermoplastic and cold forming materials (Alu-Alu).
- It stands out for its simple operation, high reliability and compact design. Its main structure is made of stainless steel.
- Automation by PLC and operation through touch screen control panel.
- It has pneumatic drives, which lend it high robustness and low maintenance.
- It is suggested for R&D departments, considering that its easy operation and maintenance makes it user-friendly to personnel that are not familiar with the use of blister machines.
Technical Parameters
| SHH-DPB Series Automatic Blister Packaging Machine | |||
| SHH-DPB80 | SHH-DPP140 | SHH-DPB250 | |
| Blanking frequency | PVC-AL: 10-40 times/min
AL-AL: 10-30 times/min |
PVC-AL: 10-40 times/min
AL-AL: 10-30 times/min |
PVC-AL: 10-40 times/min
AL-AL: 10-30 times/min |
| Adjustable scope of feed travel | 30-100mm(adjustable) | 30-120mm(adjustable) | 30-140mm(adjustable) |
| The max forming area and depth | 120mm×90mm×20mm | 150mm×120mm×26mm | 240mm×130mm×26mm |
| Wrapper: ALU | Length: 130mm, thickness: 0.02-0.035mm |
Length: 160mm, thickness: 0.02-0.035mm |
Length: 250mm, thickness: 0.02-0.035mm |
| Wrapper: PVC | Length: 130mm, thickness: 0.25-0.5mm |
Length: 160mm, thickness: 0.25-0.5mm |
Length: 250mm, thickness: 0.25-0.5mm |
| Wrapper: PTP | Length: 130mm, thickness: 0.02-0.035mm |
Length: 160mm, thickness: 0.02-0.035mm |
Length: 250mm, thickness: 0.02-0.035mm |
| Wrapper:Dialysis paper | Length:130mm, specification:50-100 gram | Length:160mm, specification:50-100 gram | Length:250mm, specification:50-100 gram |
| Power of forming heating | 1.5KW | 2.4KW | 3KW |
| Power of sealing heating | 1.5KW | 2.4KW | 3KW |
| Main motor power | 0.75KW | 1.5KW | 1.5KW |
| Machine Voltage | 380V/220V 50Hz | ||
| Capacity of air compressor | ≥0.2m3/min Pressure: 0.4～0.6MPa |
≥0.2m3/min Pressure: 0.5～0.7MPa |
≥0.2m3/min Pressure: 0.5～0.7MPa |
| Overall dimension | 2070mm×650mm×1060mm | 2350×580×1500 mm | 3100×670×1650mm |
| Weight | 560Kg | 800KG | 1500KG |
Tablet Example
